Kaleja schede controllo

facilmente regolabili per motori a corrente continua a spazzole e Brushless DC e BLDC


M2-MR-5-30 (06.34.001)

Nominal current : 5 A

Characteristics
  • rotation reversal
  • speed control
  • start ramp
  • dynamic brake
  • analog input
Voltage 24 - VDC Connection - screw terminals

M3-4Q-5-30 (06.34.002)

Nominal current : 5 A

Characteristics

  • rotation reversal
  • speed control
  • IxR compensation
  • start ramp
  • dynamic brake
  • overcurrent limitation
  • overcurrent shutdown
  • manual adjustment elements
  • analog input
  • Digital Output
Voltage 24 VDC Connection push-in terminals

M3-2QB-5-12 (06.34.006)

Nominal current : 5A

Characteristics

  • rotation reversal
  • speed control
  • start ramp
  • stop ramp
  • dynamic brake
  • overcurrent limitation
  • overcurrent shutdown
  • manual adjustment elements
  • analog input
  • Digital Output

Voltage 12 VDC Connection push-in terminals

M2-MWT-6-30 (06.34.007)
Nominal current : 6 A

Characteristics

  • rotation reversal
  • dynamic brake
  • overcurrent shutdown
  • manual adjustment elements
  • Digital Output

Voltage 24 VDC Connection push-in terminals

M2-MWI-6-30 (06.34.008)
Nominal current : 6 A

Characteristics

  • rotation reversal
  • dynamic brake
  • overcurrent shutdown
  • manual adjustment elements
  • Digital Output

Voltage 24 VDC Connection screw terminals

M3-2QB-5-30 (06.34.010)
Nominal current : 5 A

Characteristics

  • rotation reversal
  • speed control
  • start ramp
  • stop ramp
  • dynamic brake
  • overcurrent limitation
  • overcurrent shutdown
  • manual adjustment elements
  • analog imput
  • Digital Output

Voltage 24 VDC Connection push-in terminals

M2-3DR-5-30 (06.34.012)
Nominal current : 5 A

Characteristics
2adjustable speed levels

  • rotation reversal
  • speed control
  • start ramp
  • stop ramp
  • dynamic brake
  • overcurrent shutdown
  • manual adjustment elements

Voltage 24 VDC Connection screw terminals

Maxi-M-8-30 (06.04.001)
Nominal current : 8 A

Characteristics

  • dynamic brake

Voltage 24 VDC Connection screw terminals

Maxi-M-8-30 (06.04.001)
Nominal current : 8 A

Characteristics

  • dynamic brake

Voltage 24 VDC Connection screw terminals

Maxi-M-8-30 (06.04.002)
Nominal current : 8 A

Characteristics

  • dynamic brake
  • rotation reversal

Voltage 24 VDC Connection screw terminals

Maxi-S-4-30 (06.04.007)

Nominal current : 4 A

Characteristics

soft braking via external braking resistor

  • start ramp
  • dynamic brake
  • manual adjustment elements

Voltage 24 VDC Connection screw terminals

M-S-6-30 (06.04.008)

Nominal current : 6 A

Characteristics

  • start ramp
  • shop ramp
  • speed control
  • dynamic brake
  • manual adjustment elements
  • analog imput

Voltage 24 VDC Connection screw terminals

Midi-M-8-30 (06.04.012)
Nominal current : 8 A

Characteristics



Voltage 24 VDC Connection screw terminals

Maxi-MW-8-12 (06.04.014)
Nominal current : 8 A

Characteristics

  • dynamic brake
  • rotation reversal

Voltage 12 VDC Connection screw terminals

M-2Q-6-30 (06.04.021)

Nominal current : 6 A

Characteristics

  • speed control
  • dynamic brake
  • overcurrent limitation
  • manual adjustment elements
  • analog imput
  • digital input

Voltage 24 VDC Connection screw terminals

M-MWI-5-30 (06.04.025)

Nominal current : 5 A

Characteristics

  • rotation reversal
  • dynamic brake
  • overcurrent shutdown
  • manual adjustment elements
  • digital input

Voltage 24 VDC Connection screw terminals

M-4Q-6-48 (06.04.032)

Nominal current : 6 A

Characteristics

  • +/- 10V analog imput
  • rotation reversal
  • speed control
  • IxR compensation
  • dynamic brake
  • overcurrent limitation
  • manual adjustment elements
  • analog imput
  • digital input

Voltage 48 VDC Connection screw terminals

M-1Q-6-30 (06.04.039)

Nominal current : 6 A

Characteristics

  • speed control
  • IxR compensation
  • dynamic brake
  • manual adjustment elements
  • analog input

Voltage 24 VDC Connection screw terminals

Maxi-1Q-4-30 (06.04.048)

Nominal current : 3 A

Characteristics

  • speed control
  • IxR compensation
  • dynamic brake
  • manual adjustment elements
  • analog input

Voltage 24 VDC Connection screw terminals

M-MZ-4-30 (06.04.051)

Nominal current : 3 A

Characteristics

  • speed control
  • rotation reversal
  • dynamic brake
  • manual adjustment elements

Voltage 24 VDC Connection screw terminals

M-BL-5-30 (06.04.054)

Nominal current : 3 A

Characteristics

  • rotation reversal
  • speed control
  • dynamic brake
  • overcurrent limitation
  • manual adjustment elements
  • analog imput
  • digital input

Voltage 24 VDC Connection screw terminals

M-MRI-3-30 (06.04.056)

Nominal current : 3 A

Characteristics

  • rotation reversal
  • speed control
  • dynamic brake
  • overcurrent shutdown
  • manual adjustment elements
  • analog imput
  • digital input

Voltage 24 VDC Connection push-in terminals

M-1Q-5-30 (06.04.059)

Nominal current : 5 A

Characteristics

  • rotation reversal
  • speed control
  • dynamic brake
  • IxR compensation
  • manual adjustment elements
  • analog imput

Voltage 24 VDC Connection screw terminals

M-BL-10-24 (06.04.066)

Nominal current : 10 A

Characteristics

  • rotation reversal
  • speed control
  • dynamic brake
  • overcurrent shutdown
  • manual adjustment elements
  • analog imput
  • digital input

Voltage 24 VDC Connection screw terminals

M-4Q-10-30 (06.04.075)

Nominal current : 10 A

Characteristics

  • rotation reversal
  • speed control
  • IxR compensation
  • start ramp
  • dynamic brake
  • overcurrent limitation
  • overcurrent shutdown
  • manual adjustment elements
  • analog imput
  • digital input

Voltage 24 VDC Connection screw terminals

M-MWS-6-30 (06.04.078)
Nominal current : 6 A

Characteristics

  • dynamic brake
  • rotation reversal

Voltage 12 VDC Connection push-in terminals

M-4Q-10-48 (06.04.083)

Nominal current : 10 A

Characteristics

  • rotation reversal
  • speed control
  • IxR compensation
  • start ramp
  • dynamic brake
  • overcurrent limitation
  • overcurrent shutdown
  • manual adjustment elements
  • analog imput
  • digital input

Voltage 48 VDC Connection screw terminals

M-RA-5-24 (06.04.093)

Nominal current : 5 A

Characteristics

  • rotation reversal
  • speed control
  • IxR compensation
  • start ramp
  • stop ramp
  • dynamic brake
  • manual adjustment elements
  • analog imput


Voltage 24 VDC Connection push-in terminals
